Relay 24VDC 16Amp SPDT PC Board Mount
$5.49
Item is in stockHurry! Low inventoryItem is out of stock
Item is unavailable
Free shipping
Free Returns
1% Donated Annually
Feature
R25-5D16-24
| Brand/Series | R25 Series |
|---|---|
| Contact Form | SPDT |
| Current Rating | 16 A |
| Current, Rating | 16 A |
| Dielectric Rating | 4000 V (RMS) (Contact to Coil) |
| Dimensions | 1.140 in. L x 1.002 in. H |
| Function | Power |
| Material, Contact | AgCdO |
| Mounting Type | PCB |
| Number of Pins | 8 |
| Relay Type | Electro Mechanical |
| Resistance, Coil | 1100 Ohms |
| Standards | UL, CSA |
| Temperature, Operating, Maximum | 70 °C |
| Temperature, Operating, Minimum | -40 °C |
| Termination | Solder |
| Voltage, Control | 24 VDC |
| Voltage, Rating | 440 VAC |
